TL 340H PRIME - WHEEL LOADER
SPECIFICATIONS
121 HP
ENGINE GROSS POWER
11,400 Kg
OPERATING WEIGHT
1.5 m3 - 2.7 m3
BUCKET CAPACITY
The CEV 5 compliant TL340H Prime is engineered for excellence, delivering unmatched performance, best-in-class fuel efficiency and superior comfort. With advanced hydraulic technology, innovative power management and robust telematics, the TL340H Prime Wheel Loader is designed to meet the demands of diverse applications and challenging terrains.
KEY BENEFITS
- High Fuel Efficiency
- Swift Operation
- High Power
-
Hydrostatic Technology
-
Power Optimization
-
Enhanced Comfort & Safety
-
Simplified Maintenance
-
Smart Connectivity
Hydrostatic Technology
- The hydrostatic pump converts mechanical power from the engine into hydraulic flow.
- The hydraulic flow is directly converted back into mechanical power by motors on the axle, eliminating the need for a transmission.
- Pressing the accelerator increases engine RPM, which boosts hydraulic flow and in turn, increases speed
High Fuel Efficiency
The self-locking feature engages when you release the accelerator, stopping movement and saving fuel
Powerful Tractive Force
The hydrostatic drive delivers high tractive force, ensuring effortless digging with no transmission loss
High Breakout Force
The Z-bar linkage delivers high breakout force ensuring smooth and efficient excavation
Speed for Maximum Productivity
With no gears or clutches, the machine accelerates faster, while the short hydraulic cycle time keeps it ahead, completing tasks at a quicker pace
Power Optimization
Powerful Engine for Ultimate Performance
- Eco-friendly Cummins QSF 4.5 4-cylinder engine that meets CEV stage V emission standards
- Delivers 20% higher power and torque
- Equipped with the latest variable geometry wastegate turbocharger
- Increases performance at low engine speeds and improves cycle time
- Features a single-module After Treatment Device (ATD) with an integrated silencer, consisting of DOC, dosing module, DPF and SCR system
- 2 work mode options: high tractive effort and high travel speed
Support Solutions
- Wide-spread dealer network for easy availability of spare parts
- Field Diagnostic Vehicle and Mobile Workshop for quicker after-sales support
- Peace of mind through extended warranty
- Extended service intervals for reduced maintenance cost
Comfort and Safety
The TL340H Prime features a unique approach to ergonomics, designed with the customer in mind. With a range of enhancements that elevate the user experience, you can expect best-in-class comfort, visibility and overall ergonomics.
Multi-color monitor for fuel, urea, speed and more
Accessible controls within easy reach
FM radio with USB port with Bluetooth connectivity
Heating, Ventilation and Air Conditioning (HVAC)
Adjustable steering for custom comfort
Smooth bucket and arm control with pilot leve
Clear Audio Speaker
Ease of Maintenance
- Easy maintenance with long service intervals and quality components
- Ground-level access to machine components
- High-clearance engine hood and dual side panels for full engine access
- Central lubrication system available as an after-market option
- Factory-fitted remote lubrication for rear axle mounting
- Single module ATD system for ease of maintenance
- Increased DEF tank capacity - 60L
