Crusher



CRUSHER

Stone Crushers for Mining

DMC 30

Technical Specifications

Excavator Weight Class :2.5 ~ 3.5 Ton
Operating Weight :265 kg
Max opening width :410 mm
Crushing Force ( End ) :25 ton
No of Cylinder ( ea ) :2
Suitable Tata Hitachi Models :TMX20 Neo, ZAXIS33U


DMC 140

Technical Specifications

Excavator Weight Class :13 ~ 20 Ton
Operating Weight :1314 kg
Max opening width :612 mm
Crushing Force ( End ) :42 ton
Overall length :1965 mm
Operating Pressure :280 kgf / cm2
Oil flow rate :170 ~220 lpm
Suitable Tata Hitachi Models :EX130, ZAXIS140H


DMC 230 RB

Technical Specifications

Excavator Weight Class :20 ~ 28 Ton
Operating Weight :2300 kg
Max opening width :780 mm
Crushing Force ( End ) :57 ton
Overall length :2480 mm
Operating Pressure :320 kgf / cm2
Oil flow rate :200~250 lpm
Suitable Tata Hitachi Models :EX200LC, EX210LC, ZAXIS220LC, ZAXIS220LC–M


DMC 330 RB

Technical Specifications

Excavator Weight Class :27 ~ 36 Ton
Operating Weight :3100 kg
Max opening width :890 mm
Crushing Force ( End ) :73 ton
Overall length :2685 mm
Operating Pressure :320 kgf / cm2
Oil flow rate :250~300 lpm
Suitable Tata Hitachi Models :ZAXIS370LCH

Disclaimer:
Specifications and features are subject to change without prior notice . The machine depicted may vary from the actual machine. Please contact our nearest office for latest specifications.
Accessories shown here are not part of the standard equipment. Performance of the machine may vary with site and operating conditions encountered.
